Vajra ply

Vajra Gold Plus(IS:710)

VAJRA GOLD PLUS Marine Plywood is manufactured from Gurjan hardwood veneers. Bonded at very high pressure and temperature with quality Phenol Formaldehyde Resin, it can withstand rigorous climatic conditions, alternate dry and wet weather. Vajra Gold+ Marine Plywood is dimensionally stable and ideal for long lasting services. It is specially made for those areas where temperature & humidity variations are maximum.

TEST I.S.I REQUIREMENT TEST RESULTS
Moisture contents 5-15% 13%
Glue sheat strength in Ind.min. 1100 N 1625 N
dry condition Avg.Min. 1350 N 1800 N
Water Resistance Ind.min. 800 N 1256 N
Avg.Min.1000 N 1525 N
mycological test Ind.min.800 N 1420 N
Avg.min.1000 N 1510 N
Tensile strength
Parallel to grain direction Min.325 Kgf./cm2 712 Kgf./cm2
Perpendicular to grain direction Min.225 Kgf./cm2 705 Kgf./cm2
Sum of both direction Min.600 Kgf./cm2 1120 Kgf./cm2
Modulus of Elasticity
Parallel to grain direction Min.avg.7500 N/mm2 9115 N/mm2
Perpendicular to grain direction Min.avg.7500 N/mm2 7300 N/mm2
Modulus of Rupture
Parallel to grain direction Min.avg.50N/mm2 95N/mm2
Perpendicular to grain direction Min.avg.30N/mm2 55N/mm2

Vajra Ply is one of the leading manufacturers of ply woods
that stand high in terms of durability and finish.
